Giordana Steel Framesets
We do not have an on-line shopping cart at this time. Please call us: (503) 480-2001 or email: sscycleworks@comcast.net
Giordana steel frames are handbuilt in Italy. But interestingly, they are made from French Excell tubing. Excell's alloys were developed for the aerospace industry, but were found to be a perfect match for bicycle tubing.
Giordana frames use stage-racing geometry. Built for the long miles, Giordana frames are comfortable, stable and efficient.
Frames available (posted below): 59cm XL Strada
Here's info from the 1994 Giordana catalogue
More info on Giordana frames and the tubing used to make them.
Here's a chart of Giordana frame geometry
59cm Giordana XL Strada frameset. New, $1,000.00
59cm seat tube x 58.5cm top tube
We have a second 59cm XL Strada in this color with a couple of scratches. New, $900.00
Pictures of the scratches are here.
- 174mm head tube
- 72.1-degree seat tube x 73-degree head tube
- Two sets of water bottle braze-ons, pump peg and downtube shifter bosses
- 1" Threaded steel fork
- Italian-threaded bottom bracket: 36mm x 24 TPI. Both sides of the shell have right-hand threads.
- 27.2mm seat post
- The wheels in the pictures below are not included. They were used only to aid in photographing the frameset.
Here's a gorgeous 59 cm Giordana XL Strada
Front view showing the flat cast fork crown and braze-ons.
The seat cluster showing the exit of the hidden internal rear brake cable
The rear triangle. Again, immaculate workmanship.
59cm Giordana XL Strada frameset with a few scratches. New, $900.00
It is identical to the 59 shown above with the scratches shown below.
Here's a small one on the head tube.
On the top head-tube lug.
Seat binder ears of the seat lug
The top tube
