Vintage Components - SunTour rear derailleurs
SunTour rear derailleurs on this page: XC Expert medium cage | XCE long cage | XCM 3040 Accushift | XC Pro MicroDrive | XC Sport | SL short cage | Radius | Sprint 9000 short-cage | XCD 4050 long-cage | Cyclone 7000 CL10-GT | Alpha 5000 short-cage | LePREEL mid-cage | Blue Line-GT Touring | Superbe Pro short cage good for parts | V-GT | VX-GT | Cyclone short-cage | Cyclone MK-II Short Cage
See also: SunTour front derailleurs | SunTour shift levers
We do not have an on-line shopping cart at this time. Please call us: (503) 480-2001 or email: sscycleworks@comcast.net
Starting with the Cyclone Mk II derailleurs in the early 1980s, SunTour began using a flat coil return spring in its upper-end rear derailleurs. This kind of spring gives a very fluid return movement. To the best of our knowledge, no other derailleur maker has used this kind of spring.
Here's a disassembled SunTour derailleur showing the flat coil return spring.
SunTour XC Expert Medium Cage rear derailleur. Used, $65.00
- Double-sprung slant parallelogram
- 8-speed SunTour Accushift or friction compatible
- Produced early-mid 1990s
- Was part of the SunTour XCE group
In lovely condition
And from the back
SunTour XCE long-cage rear derailleur. Used
- Produced late 1980s - early 1990s
- SunTour 7-speed Accushift index or friction compatible
We have two versions available: #1 | #2
SunTour XCE long-cage rear derailleur #1. Used, $35.00/each
Not new, but perfectly servicable.
Top view
Back of the derailleur
From the back
SunTour XCE long-cage rear derailleur #2. Used, $35.00/each
A long cage for big freewheels
From the front
And the back of the derailleur
SunTour XCM 3040 Accushift rear derailleur. Used, $40.00
- SunTour Accushift index and friction compatible
- Produced in the late 1980s
aluminum alloy and steel construction
Top/front view
From behind
From the back of the derailleur
SunTour XC Pro MicroDrive rear derailleur. New, $200.00/each
Part# 75300
- SunTour part# RD-XP00-SSB
- SunTour's MicroDrive system used smaller diameter chainrings and rear cogs, by reducing the number of teeth in both. This increased frame clearance and reduced weight. SunTour said it made for faster, smoother shifts and eliminated chain jam.
- Accushift Pro compatible
- Sealed bearing pulleys
A very tidy, efficient little derailleur.
Top view
The back of the derailleur
From behind
New, in the box
The other side of the box with more info.
SunTour XC Sport rear derailleur.
SunTour XC Sport rear derailleur #1. Very lightly used, $100.00/each
This derailleur has a coiled watch return spring. The derailleur has been completely re-lubed and is ready to go.
In terrific condition
The back of the derailleur
Front view
And from behind
SunTour XC Sport rear derailleur #2. Used, $60.00/each
Clearly made for bigger freewheels.
A slightly different view
From the back of the derailleur
From the front
And from behind
SunTour SL short cage rear derailleur. New, $100.00
Part# 75100
- SunTour part# RD-SL00-SSB
- Produced 1991 - 1994
- 195 grams
- SunTour Accushift index or friction
- Designed to handle up to a 26-tooth rear cog
- We have three in stock.
Clean, neat, functional SunTour design
From the back
It is new, in the box.
SunTour Radius rear derailleur. New, $65.00/each
Part# 75310
- SunTour part# RD-RAOO-SSB
- Produced 1990 - 1992
- Will handle up to a 28-tooth rear cog.
A close-up view
From the front.
From behind
From the back.
It's new, in the box.
SunTour Sprint 9000 rear derailleur.
- SunTour part#: RD-SP10-SSB
- In 1987 SunTour redesigned the Sprint components. The rear derailleur got a new cage, parallelogram and name. It became the Sprint 9000. This new derailleur was produced from 1987 until 1990.
- It will index 6 & 7 speed Accushift Winner Pro freewheels with the correct Sun Tour indexing levers.
- SunTour's intention was for the Sprint components to compete against Shimano 600 and to fit between Sun Tour Superbe Pro and Cyclone lines.
- Weight: 200 grams.
We have two: Lightly used | Used
Sprint 9000 rear deraileur. lightly used, $100.00
Part# RD-83-LU
The pulleys show how little use this derailleur has had.
And just as nice from the back.
Sprint 9000 rear deraileur. used, $50.00
Part# RD-83-U
Used, but still works well.
From the back
And from the top
SunTour XCD 4050 long-cage rear derailleur. Used, $50.00
- SunTour 6 or 7-speed Accushift or friction compatible
- Produced about 1987
From the front
And from the back
SunTour Cyclone 7000 CL10-GT rear derailleur. Used, $85.00
- Produced 1987 - 1988
- SunTour Cyclone 7000 was one of SunTour's first generation Accushift groups
- This derailleur has a floating jockey wheel using bearings.
The adjustment screw placement makes adjusting this derailleur easy.
The back of the derailleur.
From behind.
Front view
Here are the pulleys. The one on the right is the jockey pulley with bearings.
You can see the jockey pulley bearings in this photo of the pulleys.
There they are all buttoned up and ready to be remounted on to the derailleur.
SunTour Alpha 5000 short-cage rear derailleur. Used, $40.00
- SunTour part# RD-5000-SS
- Produced around 1987
- About 270 grams
- SunTour Accushift index or friction shifter compatible
From the front
And from the back.
SunTour LePREEL Mid-cage rear derailleur. Used, $60.00/each
- Produced mid to late 1980s
- SunTour sold this friction rear derailleur under both the "LePREE" and "LePREEL" names depending on how the company felt the different names would do in different markets. This created no end of confusion among SunTour fans. To cut the Gordian Knot: They are the same derailleur, with or without the final "L".
Mid-cage offers a sharp shifting derailleur and a good gear range.
From the front.
From behind
The back of the derailleur
SunTour BL GT wide-range rear derailleur. Used
- Both of these derailleurs were completely taken apart and fresh grease installed in the springs and pulleys.
- The "BL" stands for "Blue Line", a series of derailleurs intended to fit above the Vx and below the Cyclone derailleurs.
- SunTour part# RD-3300
- The BL derailleurs were made starting in 1981 and through at least 1984.
- Weight: 220 grams
- Though named "Blue Line", most BL derailleurs were made with black trim.
SunTour BL GT wide-range rear derailleur #1. Used, $80.00
- We tapped a new stop in the cage. It won’t pull up as much chain slack as before, but we wanted to save a blue Blue Line.
- This BL derailleur does have blue trim.
A BL rear derailleur with blue trim.
From this angle you can see the new placement of the cage-wrap stop screw and where the old one was.
From behind
From the front
The back of the derailleur
The back of the derailleur from another angle
Here we are tapping a new hole for the cage stop screw.
SunTour BL GT wide-range rear derailleur #2. Used, $100.00
Lovely condition
Head-on view
From behind
From underneath
The back of the derailleur
SunTour Superbe Pro short cage friction rear derailleur, good for parts. Used, $25.00
- Here's a great derailleur for spare parts.
- Produced 1983 - 1986
- SunTour part #RD-5200
- Sealed bearing pulleys.
- Factory specs say max cog size is 26, but depending on dropout geometry and wheel placement, it can sometimes be made to throw a 28.
disraeligears.co.uk said this about the SunTour Superbe: "Many people regard the SunTour Superbe Pro (5200) as the finest friction derailleur of all time. It was light, strong, extremely effective and constructed to fantastic tolerances from the finest materials.
"No detail was overlooked, from the aluminium hanger bolt and pulley bolts to the sealed bearing pulley wheels to the stainless steel pivots with Allen heads that were removable so that the gear could be completely disassembled."
It's missing a pulley
And from the back it can be seen that there are broken and bent pieces.
SunTour V-GT rear derailleur. Used, $50.00
- SunTour part #4900
- SunTour made several versions of this derailleur. This might be version 2C or 2D.
- It was produced from 1971 until 1973.
Hard to believe this derailleur is 50 years old.
From the front
It has a mix of steel and aluminum parts.
From behind
From behind at a slightly different angle
Back of the derailleur
SunTour VX-GT rear derailleur. Used, $60.00/each
- The VX was introduced in either 1976 or 1977 and was produced into 1981.
- The VX is essentially a slimmed-down SunTour V. It has more aluminum and has a neater, cleaner design.
- Our VX rear derailleur has been overhauled and is ready for use.
This will shift almost anything.
The back of the derailleur
From the front
From behind.
SunTour Cyclone shortcage rear derailleur, 2nd-style. Used
- Produced about 1975
- Made for a maximum cog of 26 teeth, but with a rear derailleur hanger dropping 32mm or more, it can handle a 28.
- Weight: Only 179 grams
- This is the second version of the Cyclone.
- This derailleur is a masterpiece of component design. The Cyclone probably shifted better than any derailleur in the world in 1976. The cable routing through the parallelogram is clever and simple.
SunTour Cyclone shortcage rear derailleur, 2nd-style #1. Used, $60.00/each
A bit scratched, but works perfectly well.
This is about as good as a friction derailleur gets.
From the back
From behind
Top view
SunTour Cyclone shortcage rear derailleur, 2nd-style #2. Used, $75.00/each
Decades old, but in lovely condition.
The back of the derailleur.
From behind
The front of the derailleur
Here's a 1970s ad for SunTour Cyclone derailleurs
SunTour Cyclone MK-II Short Cage rear derailleur. Used, $65.00/each
- This derailleur has been overhauled.
- SunTour part# RD-3500
- SunTour introduced this derailleur in 1981
- SunTour says the maximum cog size this derailleur can handle is 26 teeth.
Though the printing has worn off, this derailleur (overhauled) will function perfectly and give years of good use.
The back of the derailleur
From the front
And from behind.
